Dây hơi PU Hwaflex

Liên hệ

Mã sản phẩm: PU1208
Thương hiệu: Hwaflex
Công nghệ: Hàn Quốc
Xuất xứ: Hàn Quốc
Bảo hành: 0
Trọng lượng: 3.0 Kg

Title:

Kích thước:

Màu sắc:

Dây hơi PU Hwaflex, Dây hơi Hwaflex, Ống hơi Hwaflex Korea

Hwaflex PU Tubing

- Ultra softness enables to display excellent efficiency in piping.
- Superior anti-pressure, anti-vibration, anti-rust, anti-heat, anti-chemical & anti-oil
- Low-absorbtive rate, low physical performance deterioration & low changeable rate of measurement.
- Outstanding anti-weater, anti-curve & anti-fatigue.
- Lightness & softness of hose enable to increase the productivity of piping work.
- Wide applicable range of temperature.
- Various tube colours make it easier to distinguish the pipes on another.
- Temperature range: -20°C ~ +80°C

Model	Size	O/D (mm)	I/D (mm)	Thickness (mm)	Burst pressure at 20°C (kg/cm2)	Min Curvature Radius (mm)	Weight (g/m)
PU0402	4x2	4.0	2.0	1.00	23	10	11
PU0604	6x4	6.0	4.0	1.00	23	15	19
PU0805	8x5	8.0	5.0	1.50	23	23	37
PU1065	10x6.5	10.0	6.5	1.75	23	30	55
PU1208	12x8	12.0	8.0	2.00	23	35	76

Mô tả

Dây hơi PU Hwaflex, Dây hơi Hwaflex, Ống hơi Hwaflex Korea

Hwaflex PU Tubing

Model	Size	O/D (mm)	I/D (mm)	Thickness (mm)	Burst pressure at 20°C (kg/cm2)	Min Curvature Radius (mm)	Weight (g/m)
PU0402	4x2	4.0	2.0	1.00	23	10	11
PU0604	6x4	6.0	4.0	1.00	23	15	19
PU0805	8x5	8.0	5.0	1.50	23	23	37
PU1065	10x6.5	10.0	6.5	1.75	23	30	55
PU1208	12x8	12.0	8.0	2.00	23	35	76
