• Provides a wide working range (5-125 ft-lb), allowing technicians to work on a wider array of popular applications, including passenger tires
• Heavy-duty yoke designed for higher torque load
• Patent-pending Snap-on® Multi Axis Gyro Compensation provides a high level of accuracy even while in a flexed position
• MAG COMP measures and compensates for changes in reaction distance due to flex angle of the torque wrench
• Snap-on® 80 tooth ratchet for optimal blend of strength and reduced swing arc at just 4.5° the shorter length and minimal swing arc works extremely well in tight engine compartments
• Standard ATECH features such as dual progressive LED’s, LCD screen with backlight, four alert modes (LED, LCD, vibratory, audible), six scales (ft-lb, in-lb, Nm, kg-cm, dNm, angle), 10 presets, torque then angle, low profile buttons, power interruption technology, cycle counter, battery level indicator and other customizable features
• Meets or exceeds ASME® B107.300-2010 (B107.28) standard
• Two year warranty
• Assembled in USA
• Engineered the yoke with more steel mass as well as an extremely tight tolerance ratchet tang-to-yoke fit
• Provides more torsional strength while still allowing smooth indexing/movement of the ratchet head (up to 15°)
• Smaller yoke/ratchet gap which reduces potential pinch point(s)
SPECIFICATIONS:
Range, ft-lb : 5–125
Range, in-lb : 60–1,500
Gear Action : 4.5°
Color : Black Housing/Chrome Body
Country Of Origin : USA
Storage Case : PBATECH100B
Gear Teeth : 80
Battery, Type (qty) : AA Alkaline (3)
Head Depth, inches : 9/16
Length, inches : 17.9
Flex Joint Repair Kit : RKRFLLF80JT
Head Width, inches : 1-1/4
Range, N•m : 6.78–169.48
Ratchet Service Kit : RKRFLLF80
Head Type : Sealed Flex Head
Square Drive, inches : 3/8
Weight (without batteries), lb (kg) : 2.2 (0.9)
